FPGA design, from RTL to field-proven hardware.
We turn your requirements into verified, timing-closed FPGA designs and licensable IP cores for signal processing, communications, video and control. We prototype on our own Alinx FPGA platforms and deliver to your hardware.
From a line of code to a configured fabric.
We write your design in VHDL or SystemVerilog, verify it against a bit-accurate model, then synthesize, place and route it until timing closes with margin. Watch a design move through the flow.
Deep FPGA engineering, end to end.
Bring us a whiteboard sketch, a MATLAB model or a legacy design that needs a new home. We take ownership of the FPGA workstream and hand back a design your team can maintain.
Architecture & specification
Requirements capture, device selection, resource and power budgets, clocking and reset strategy, interface definition. We fix these before any RTL is written.
RTL design
Clean, parameterized VHDL and SystemVerilog with lint-clean coding standards, CDC-safe clock crossings and synthesis-friendly structures.
UVM verification
Constrained-random testbenches, functional coverage, assertions and bit-accurate C/MATLAB reference models, so what you simulate is what you ship.
High-speed & SerDes
Multi-gigabit transceivers, JESD204B/C data-converter links, PCIe, 10/25G Ethernet, DDR4 memory interfaces and timing closure at high clock rates.
SDR, RF & DSP
DDC/DUC, polyphase filters, FFT, OFDM, LDPC and DPD. Complete digital signal chains for radios, datalinks and electronic warfare.
Video & imaging
Camera interfaces, ISP pipelines, H.264/H.265 codecs, overlays and low-latency streaming for ISR and FPV systems.
Porting & obsolescence
Migrate legacy designs between vendors and families, refresh end-of-life parts and re-verify against the original behaviour.
Custom IP cores
New IP built to your specification, delivered in 2–5 months as encrypted netlist or source, with testbench, model and documentation.
ASIC prototyping
Prove your ASIC RTL on FPGA before tape-out, with the same verification environment carried through to silicon.
Custom IP in 2 to 5 months.
Every project follows the same gated flow. The complexity sets the duration. Pick a project size to see how a typical engagement is planned.
Indicative plans. The exact schedule is agreed at kickoff after the requirements review.
Proven on real silicon, on our own benches.
Every design is brought up on our in-house Alinx FPGA development platforms before it reaches you. Your IP is tested at speed on real transceivers, DDR memory and I/O, not only in simulation.
- In-house Alinx AMD FPGA platforms for bring-up and demos
- Hardware-in-the-loop test with data converters and RF front-ends
- Reference designs delivered with your IP
- Porting to your own board once the design is proven
Engineers who ship FPGA designs.
RTL design
Hardware
Verification
Design reviewEvery major FPGA ecosystem.
Devices & vendor tools
Languages, verification & interfaces
What you receive
- Synthesizable RTL or encrypted netlist
- Self-checking testbench and test vectors
- Bit-accurate C / MATLAB reference model
- Timing, resource and power reports
- Vivado IP catalog / Platform Designer packaging
- Design documentation and integration guide
- Reference design on hardware
- 12 months of engineering support
Tell us what the FPGA must do.
Send a requirements summary or a block diagram. We reply with an architecture proposal, a schedule and a fixed-scope quote.
- Fixed-scope proposals within days
- NDA-first engagement
- Altera Design Partner
- Designed and verified at Teknopark İstanbul
